TANNER MDA water-supplied air heater

The most versatile hot water air heater on the market

The TANNER MDA range of LPHW unit heaters, are a water-supplied suspended air heater which can expel air horizontally or vertically. The unit has a powerful axial fan which means it is suitable for many applications. Mark offers a highly extensive range of accessories for the TANNER MDA allowing it to be aligned to all applications. For example, the unit can be made suitable for external air connection in combination with filtering and a mixing box for the destratification of fresh external air. The unit is also available as an ATEX / EEX-model. (400V) – IP 44 (Ex II 2 G c Ex e IIB T3).

The TANNER MDA is designed for use in showrooms, changing rooms, industrial halls and garages.

Cooling with a water-supplied air heater

In addition to the standard TANNER MDA unit heaters, we also have MDA+ units available. Thanks to an integrated drip tray, these air heaters can both heat and cool.

Remote Connection

The Pintherm Connect can be used to control the Mark TANNER MDA(+). The controller is equipped with an on/off contact and a 0-10VDC output. The settings of the thermostat can be read and/or modified with Modbus or Ethernet. This makes it possible to operate the LPHW air heater remotely. The thermostat can also be connected to the BMS (building management system).

  • Manufactured with a corrosion-resistant aluzinc housing as standard
  • Copper/aluminium heat exchanger
  • Highly versatile due to extensive configuration options
  • Available as 230V or 400V
  • IP class 54
Optional: EC-motor

Speed controlled low noise EC-motor (230V/0-10V).  Advantages:

  • The highest efficiency in case of speed control
  • Up to 50% energy saving in case of partial load
  • Almost completely linearly adjustable
  • Long lifetime
  • Low noise level
  • Integrated electronic thermal protection
Interested in the TANNER MDA water-supplied air heater Request a quote
