GSX gas-fired air heater
Economical heating with the GSX gas-fired air heater
With the Mark GSX gas-fired air heater, heat is generated via a premix-burner and blown out by means of an axial fan. The robust air heater is particularly suitable for industrial use and is very economical thanks to its low gas consumption, low maintenance and long lifespan.
The Mark GSX series fully complies to the new Ecodesign 2021 and has a capacity range of 13,7 to 84,6 kW.
The GSX is suitable to heat garages, warehouses, workshops, distribution centers, showrooms and more.
Remote Connection
The GSX is operated using an Optitherm+ clock thermostat or an Interface+ module that allows a connection with the BMS (building management system) via Modbus.
Optimal heat distribution
The Mark air heaters are commonly installed in combination with destratification fans. The ECOFAN W destratification fans ensure both optimum distribution of warm air and comfort in the room. A thermostatically-controlled ECOFAN transports the warmth under the roof to the occupied area. As a result, the room warms up more quickly, and gas consumption can in some cases be reduced by up to 30%.
Hybrid control
Do you want to reduce the gas consumption of your industrial hall or space? Then take advantage of our Hybrid Controller. This hybrid controller allows you to combine an existing or new gas-fired air heater with our Mistral MDX heat pump system. The installed capacity of the Mistral MDX unit can be low because the gas-fired heater(s) provide the capacity needed during severe cold. This way one saves significantly on energy costs.
- Long lifespan
- Low operating costs
- Robust
- Reliable
- Uniform temperature distribution through high air displacement
- Small ΔT
- Small difference between supply air and room temperature
- Control up to 8 units possible via a 2-wire bus system
- Zone heating possible via 1 control (up to 8 zones)
- Stainless steel heat exchanger
- Closed combustion circuit
- Premix burner
- Electronic ignition
- Aluzinc coating
- Powerful axial fan(s)
- Downflow hood with horizontal louvres
- CE-approval
- No condensation pipe required
The GSX is standard equipped with a speed-regulated, low-noise EC fan
- The highest efficiency in case of speed control
- Up to 50% energy saving in case of partial load
- Almost completely linearly adjustable
- Long lifetime
- Low noise level
- Integrated electronic thermal protection
