3D BIM models of the Mark MISTRAL MDX now available

Mark is expanding its library of 3D BIM models with VRF heat pump systems

Mark Climate Technology’s BIM library has been expanded with the 3D models of the MISTRAL MDX. This VRF heat pump system is specially developed for energy-efficient heating and cooling of large spaces. The combination of an air-to-air heat pump (outdoor unit) with a compact air heater / cooler (indoor unit) ensures excellent performance. Thanks to the extensive setting options, the installation can be fully adapted to the use of the building and the wishes of the users.

The 3D BIM models of the Mistral MDX, together with those of many other Mark products, can be downloaded as Revit .RFA, AutoCAD .DWG and .IFC files via the online BIM library MEPcontent and on our website.

Product features MISTRAL MDX

Product features MISTRAL MDX

  • Available with powers of 33 kW and 56 kW
  • Air to air heat pump VRF-system
  • Cooling and heating
  • Large temperature range
  • Indoor unit with EC fan
  • Energy efficient
  • Pipe length: 90m MDX 33 / 170m MDX 56
  • Refrigerant: R410a
  • Optional: integrated condensate pump
More information about the MISTRAL MDX
What is BIM?

What is BIM?

BIM (Building Information Modeling) is an online software platform in which all information about a construction project is managed in one digital 3D model. In this model, all parties involved can simultaneously consult and change the information that is important to them. Because the project information is always up to date and available to all involved, the chance of errors during the construction process is significantly reduced.

View all 3D BIM models from Mark
